Canvas绘图及描框

canvas绘制图片和画识别框问题

canvas知识

前言

先说一下业务需求，此处的功能是用于微信OCR文字识别的PC端和小程序端应用。要求上传本地图片后，图片以及识别结果能够展示，为便于测试要求在识别图片上对识别的文字用矩形框及序号框出，与结果一一对应。

记录下此处的实现方法及难点：

1、首先图片显示不要使用img标签，使用canvas来描绘，我们需要得到的是img的宽高属性。小程序使用：wx.getImageInfo，vue中直接new Image()

2、我们要知道两个比例：（1）图片与画布的比例，用于图片自适应画布大小。（2）图片自身缩放比例，
用于识别框同比例缩放。

3、计算居中显示的偏移量：（画布-图片）/2；调用canvas的api接口绘图ctx.drawImage

4、根据后台返回的坐标点（原图）进行描框和缩放ctx.strokeRect，对序号框字体进行优化，自适应框的大小，此处小程序和pc不同。

分别附带小程序及vue的完整代码

小程序：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
97
98
99
100
101
102
canvasToFile(ctx) {
    const cWidth = 640,
      cHeight = 480;

    wx.getImageInfo({
      src: SRC,
      success: res => {
        // 原始图大小
        let imgWidth = res.width,
          imgHeight = res.height;
        // 相对画布等比例缩放
        let n = 1;
        if (imgWidth > imgHeight) {
          n = imgWidth / cWidth;
          imgWidth = cWidth;
          imgHeight = imgHeight / n;
        } else {
          n = imgHeight / cHeight;
          imgHeight = cHeight;
          imgWidth = imgWidth / n;
        }
        // 图片自身缩放比例
        let widthScal = imgWidth / res.width;
        let zoom = {
          width: widthScal,
          height: widthScal
        }
        // 偏移x,y位移量
        let right_move = (cWidth - imgWidth) / 2;
        let bottom_move = (cHeight - imgHeight) / 2;
        // 缩放展示画布图片
        ctx.scale(0.5, 0.5);
        ctx.drawImage(SRC, right_move, bottom_move, imgWidth, imgHeight);
        ctx.draw();
        // 画矩形识别框
        setTimeout(function() {
          let value = wx.getStorageSync('ocr');
          if (value.hasOwnProperty('items')) {
            let length = value.items.length;
            let item = value.items;
            for (let i = 0; i < length; i++) {
              let show = item[i];
              // 原图坐标
              let X1 = show.pos.left_top.x;
              let Y1 = show.pos.left_top.y;
              let X2 = show.pos.right_bottom.x;
              let Y2 = show.pos.right_bottom.y;
              let startPoint = [X1, Y1],
                endPoint = [X2, Y2];
              // 等比例缩放坐标
              let Num_x = startPoint[0] * zoom.width + right_move;
              let Num_y = startPoint[1] * zoom.height + bottom_move;
              let Num_width = (endPoint[0] - startPoint[0]) * zoom.width;
              let Num_height = (endPoint[1] - startPoint[1]) * zoom.height;
              ctx.setStrokeStyle('blue');
              // 分别画两个画布的矩形框
              ctx.strokeRect(Num_x, Num_y, Num_width, Num_height);
              // 区分文字横向，竖向展示时，数字框位置
              if (Num_width < Num_height) {
                let top_x = Num_x;
                let top_y = (startPoint[1] - (endPoint[0] - startPoint[0])) * zoom.height + bottom_move;
                let w_h = Num_width;
                ctx.setFontSize(w_h);
                ctx.setStrokeStyle('#006bff');
                ctx.setFillStyle('#006bff');
                ctx.fillText(i + 1, Num_x + (w_h / 2), Num_y, w_h);
                ctx.strokeRect(top_x, top_y, w_h, w_h);
                ctx.setTextAlign('center');
              } else {
                let left_X = (startPoint[0] - (endPoint[1] - startPoint[1])) * zoom.width + right_move;
                let left_Y = Num_y;
                let W_H = Num_height;
                ctx.setFontSize(W_H);
                ctx.setStrokeStyle('#006bff');
                ctx.setFillStyle('#006bff');
                ctx.fillText(i + 1, left_X + W_H / 2, left_Y + W_H, W_H);
                ctx.strokeRect(left_X, left_Y, W_H, W_H);
                ctx.setTextAlign('center');
              }
            }
            ctx.draw(true)
            // 导出图片到url数组中，注意像素值
            ctx.draw(true, setTimeout(function() {
              let dpr = wx.getSystemInfoSync().pixelRatio
              wx.canvasToTempFilePath({
                x: right_move,
                y: bottom_move,
                width: imgWidth,
                height: imgHeight,
                destWidth: imgWidth * dpr,
                destHeight: imgHeight * dpr,
                canvasId: 'canvas_pre',
                success(res) {
                  url.push(res.tempFilePath)
                }
              })
            }, 100));
          }
        }, 1200)
      }
    })
  },

在onload调用该方法并初始化：

1
2
3
4
const ctx = wx.createCanvasContext('canvas')
ctx.clearRect(0, 0, 320, 240)
ctx.draw()
this.canvasToFile(ctx)

vue中实现：

调canvas组件：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
<template>
  <Canvas @upload="upload" :result_show="result_title"
          :list="ocr_comm" :show="loading" :err="err"></Canvas>
</template>

<script>
  import Canvas from 'components/HomeChildren/Canvas/Canvas'

  export default {
    name: "ocr_comm",
    components: {
      Canvas
    },
    data() {
      return {
        CW: '400px',
        CH: '400px',
        result_title: '通用OCR识别结果',
        ocr_comm: [],
        loading: false,
        err: false
      }
    },

图片自适应及绘图，使用async解决异步影响：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
async upload(file, canvas) {
        if (!file) return;
        // 加载图标显示
        this.loading = true
        // 图片缩放比例
        let widthScal = 0
        // 先基于FileReader进行文件的读取
        let fileExample = new FileReader();
        fileExample.readAsDataURL(file);
        fileExample.onload = ev => {
          // 创建新图片
          this.IMAGE = new Image();
          this.IMAGE.src = ev.target.result;
          this.IMAGE.onload = () => {
            this.IW = this.IMAGE.width;
            this.IH = this.IMAGE.height;
            const NCW = parseInt(this.CW);
            const NCH = parseInt(this.CW);
            // 重新按照比例计算宽高
            let n = 1;
            if (this.IW > this.IH) {
              n = this.IW / NCW;
              this.IW = NCW;
              this.IH = this.IH / n;
            } else {
              n = this.IH / NCH;
              this.IH = NCH;
              this.IW = this.IW / n;
            }
            this.IL = (NCW - this.IW) / 2;
            this.IT = (NCH - this.IH) / 2;
            widthScal = this.IW / this.IMAGE.width;
            // 绘制图片
            this.CTX = canvas.getContext("2d");
            // 清空画布
            this.CTX.clearRect(0, 0, parseInt(this.CW), parseInt(this.CH));
            // 绘制图片
            this.CTX.drawImage(this.IMAGE, this.IL, this.IT, this.IW, this.IH);
          };
        }
        //上传文件
        await this.uploadImg(file)
        this.strokeRect(widthScal)
      },

描框代码，这里的序号字体自适应使用字符串拼接形式：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
strokeRect(widthScal) {
        if (this.ocr_comm.length !== 0) {
          for (let i = 0; i < this.ocr_comm.length; i++) {
            let show = this.ocr_comm[i];
            // 原图坐标
            let X1 = show.pos.left_top.x;
            let Y1 = show.pos.left_top.y;
            let X2 = show.pos.right_bottom.x;
            let Y2 = show.pos.right_bottom.y;
            let startPoint = [X1, Y1],
              endPoint = [X2, Y2];
            let Num_x = startPoint[0] * widthScal + this.IL;
            let Num_y = startPoint[1] * widthScal + this.IT;
            let Num_width = (endPoint[0] - startPoint[0]) * widthScal;
            let Num_height = (endPoint[1] - startPoint[1]) * widthScal;
            this.CTX.strokeStyle = 'blue';
            this.CTX.strokeRect(Num_x, Num_y, Num_width, Num_height);
            if (Num_width < Num_height) {
              let top_x = Num_x;
              let top_y = (startPoint[1] - (endPoint[0] - startPoint[0])) * widthScal + this.IT
              let w_h = Num_width;
              let fontsize=w_h+'px';
              let fontFamily="宋体";
              let Num_font=fontsize+' '+fontFamily;
              this.CTX.font=Num_font;
              this.CTX.strokeStyle = '#006bff';
              this.CTX.fillStyle = '#006bff';
              this.CTX.fillText(i + 1, Num_x + (w_h / 2), Num_y, w_h);
              this.CTX.strokeRect(top_x, top_y, w_h, w_h);
              this.CTX.textAlign = 'center';
            } else {
              let left_X = (startPoint[0] - (endPoint[1] - startPoint[1])) * widthScal + this.IL
              let left_Y = Num_y;
              let W_H = Num_height;
              let fontsize=W_H+'px';
              let fontFamily="宋体";
              let Num_font=fontsize+' '+fontFamily;
              this.CTX.font=Num_font;
              this.CTX.strokeStyle = '#006bff';
              this.CTX.fillStyle = '#006bff';
              this.CTX.fillText(i + 1, left_X + W_H / 2, left_Y + W_H, W_H);
              this.CTX.strokeRect(left_X, left_Y, W_H, W_H);
              this.CTX.textAlign = 'center';
            }
          }
        } else {
          console.log("数据未取到");
        }
      },

上传代码到后台服务器，前端使用api代理解决跨域问题：

1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
async uploadImg(file) {
        var forms = new FormData();
        forms.append('file', file);
        let config = {
          headers: {'Content-Type': 'multipart/form-data'}
        };
        await this.$axios.post('/apidebug_imagequery?action=ocr_comm', forms, config)
          .then(res => {
            this.loading = false;
            if (res.data.ocrcomm_res.items.length !== 0) {
              this.ocr_comm = res.data.ocrcomm_res.items;
              this.err = false;
            } else {
              this.ocr_comm = [];
              this.err = true;
            }
          }).catch(err => {
            //补充异常处理代码
            console.log(err);
          })
      },

至此！canvas的相关实现就是这些。canvas远比自己想的强大，现在所知也是九牛一毛，以后再会~！
